Environmental IPX5 IPX6 water shower test chamber
Environmental IPX5 IPX6 water shower test chamber
Environmental IPX5 IPX6 water shower test chamber
Environmental IPX5 IPX6 water shower test chamber
Model
HUD-E710-3 water shower test chamber

Item specifics

Observation window
Waterproof Toughened glass
IP Code
IPX5,IPX6
Test duration
0~999h59min
Controller
PLC touch screen
Distance from nozzle to enclosure surface
2.5m ~ 3m
Water cycling system
Built-in chamber bottom for recycling

Product review

Description

Features

1.SUS304 stainless steel box

2. Sprinkler pipe made of seamless stainless steel

3 .Nozzle removable and equipped with a plug, to facilitate customer replacement

4. The bottom of the fixed PU movable wheel

5. Equipped with water filtration device

6. Sample stage speed adjustable

Standard

JIS, ISO, IEC60529, DIN40050, GB2423, GB4208.

Paramater

Item

Specification

Internal chamber size

800Wx800Dx800Hmm

External chamber size

1200Wx900Dx3300Hmm

IP Code

IPX5

IPX6

Internal diameter of spray nozzle

6.3mm

12.5mm

Delivery rate

12.5l/min±5%

100l/min±5%

Core of the substantial stream

Circle of approximately 40mm diameter at 2.5m distance from nozzle

Circle of approximately 120mm diameter at 2.5m distance from nozzle

Chamber material

Internal: SUS304 stainless steel, external: stainless steel

Test duration per square meter of enclosure surface area likely to be sprayed

1 min

Minimum test duration

3 min

Controller

PLC touch screen

Turntable

Diameter 300mm, rotate speed 3±1R/min

Distance from nozzle to enclosure surface

Between 2.5m and 3m
